From a described process to a ready .bpmn file: a BA skill in Claude Code

Understanding a larger, unfamiliar process usually means hours of clicking inside a modelling tool — or hand-writing BPMN XML with correct coordinates, which is error-prone and gets rewritten from scratch every single time. I built a skill that cuts that short: you describe the process in words, and you get an AS-IS/TO-BE model in ASCII, the rules for every gateway, the edge cases — and a real .bpmn file with auto-layout that opens straight in bpmn.io.

What it actually is

process-mapper is a Claude Code skill that turns a described process into a full set of business-analyst (BA) artifacts. I frame it deliberately: it’s an accelerator for bigger processes, not a replacement for learning to model by hand. Doing it manually in bpmn.io stays my BA learning path — the skill only scales the analysis itself.

The core is generated every time, as text:

• AS-IS — the current state, with bottlenecks and rework loops.
• TO-BE — the target state, with an explicit split: ⚙️ service task (automation/AI) versus 👤 user task (a human).
• Rules for every gateway — the condition, plus a label on each exit path.
• Edge cases — what breaks, and how the process catches it.
• Actors + swimlanes — who performs which step (one lane per actor/system).

Everything comes out as ASCII plus a .bpmn file — never mermaid or a rendered widget, on purpose. The reason is practical: rendered diagrams don’t load in my environment — they show up blank. ASCII always loads, and .bpmn is the hard, editable artifact. The whole thing points one way: learning and a portfolio aimed at a junior BA / AI BA role.

Under the hood

The .bpmn file is produced by a script, build_bpmn.py. You feed it a simple, declarative JSON spec — two keys, elements and flows — and the script assembles valid BPMN 2.0 XML with auto-layout (DI). It supports 6 element types, each mapped to a BPMN element:

start    → startEvent
end      → endEvent
task     → task
service  → serviceTask
user     → userTask
gateway  → exclusiveGateway

The interesting part is the auto-layout, because that’s what removes the manual coordinate math. A longest-path ranking algorithm (Kahn’s topological order with longest-path propagation) computes each node’s column as its distance from the start. Nodes that share a rank are spread vertically around a baseline, with fixed spacing: 160 px horizontally, 120 px vertically. From that it emits BPMNShape (with dc:Bounds) and BPMNEdge (with di:waypoint) — the entire visual layer bpmn.io needs to draw anything at all.

Two design decisions are deliberate. First, lanes and pools are not generated — I draw them in by hand in bpmn.io, because that’s a BA exercise too. Second, the script validates its input: a missing elements or flows key ends it with a hard error instead of spitting out garbage.

A second layer of discipline lives in the analysis, not the code. Every gateway must have at least two named exit paths — a gateway without labels I treat as an error, because it signals a process that hasn’t been thought through. And there’s a fixed edge-case checklist I walk for every TO-BE:

- error / exception   → retry, error path, escalation
- missing data        → validation
- low confidence      → gateway on confidence → human correction (human-in-the-loop)
- rejection           → loop back
- duplicate           → deduplication
- timeout             → no response
- compliance          → where a human should sign off (a compliance practice tied to GDPR art. 22)

What you get

The most important thing this skill shows is BA maturity, not a pretty picture. The model doesn’t stop at the happy path: every gateway branch is named, the edge cases are worked through, and human-in-the-loop is built in wherever a person has to stay in the loop (low confidence, compliance). That’s the difference between “I drew a diagram” and “I thought the process through.”

Second, the bridge to real tools. On request the skill adds optional modules: UML as ASCII (sequence and/or class), Jira-ready user stories in the “As a [role] I want [goal] so that [value]” format with “Given / When / Then” acceptance criteria, and API field mapping (source → target → transformation rule + handling for missing values). The stories are designed for the Atlassian connector (ready to create as issues), and the field-mapping pattern points straight at my OCR product’s pipeline (Azure DI → schema → export, e.g. tax ID, date, amount).

Third, it’s deterministic automation where the work used to be tedious and manual (generating XML), while consciously keeping the manual learning. The script does what a machine does better (correct coordinates and waypoints), and I keep what builds the skill (modelling, lanes). The result is showable: a BRD + .bpmn + stories for one product is a “BA folder” — material to bring straight into an interview.

Proof

No public repo yet — the skill lives locally as a Claude Code skill (~/.claude/skills/process-mapper), so the proof here is the technique and a working artifact, not a GitHub link.

I checked that the generator actually runs. On a sample spec, “Invoice handling” (7 elements + 7 flows), it produced a .bpmn file that is well-formed BPMN 2.0 XML — confirmed with a parser — with sequenceFlow, BPMNShape (dc:Bounds) and BPMNEdge (di:waypoint) elements. In other words, ready to open in bpmn.io. Here’s the input and output for a single gateway:

spec (JSON):
  {"id": "gw", "type": "gateway", "name": "Confidence high?"}
  {"from": "gw", "to": "fix", "label": "No"}
  {"from": "gw", "to": "ok",  "label": "Yes"}

.bpmn (excerpt):
  <bpmn:exclusiveGateway id="gw" name="Confidence high?" .../>
  <bpmn:sequenceFlow ... sourceRef="gw" targetRef="fix" name="No" />
  <bpmn:sequenceFlow ... sourceRef="gw" targetRef="ok"  name="Yes" />
  <bpmndi:BPMNShape ...><dc:Bounds x="..." y="..." width="50" height="50" /></bpmndi:BPMNShape>

An honest caveat: I verified the XML’s well-formedness and the presence of the DI layer, but I didn’t open the file visually in bpmn.io — so I’m not claiming a “perfect layout,” only a valid, openable artifact.

If you’re curious how skills and tools like this fit the bigger picture of AI adoption, I wrote about it from the data side: what the data says about AI adoption — Poland vs the EU.
